Cheap Prefabricated Workshop Prefab Steel Structure Storage Modular Warehouse Metal Construction Shed Storage Building
|
Item
|
Prefab steel structure workshop,warehouse,hangar ,hall building
|
|
Model
|
Single slope, double slope, multi slope. Single span, double-span, Multi-span Single floors, Double floors
|
|
Main steel grade
|
Q235B, Q345B
|
|
Column & Beam
|
Welded or Hot rolled H-section steel, constant cross-section or variable cross-section. H 160~2000*150~800*6/8/10*6/8/10/12mm.
Two coats of primer and finish paint.
|
|
Wall & Roof
|
EPS, Fiber glass, Rockwool, PU sandwich panel 50/75/100mm, and corrugated steel sheet 0.5~0.8 mm
|
|
Wall & Roof purlin
|
C / Z channel steel, Hot dip galvanized. C80~C300, Z100~Z300
|
|
Bracing
|
X or V type Steel round bar, Angle steel and tubes, painted or galvanized.
|
|
Strut
|
Steel round pipe and tube, and angle steel, painted.
|
|
Sag rod
|
Steel round bar, galvanized.
|
|
Eave Gutter
|
Galvanized / Stainless steel sheet
|
|
Downspout
|
UPVC pipe Diameter 110mm
|
|
Trim & Flashing
|
Bended color steel sheet
|
|
Door
|
Roll-up, Sliding, Lifting and Hinged door etc
|
|
Window
|
Plastic steel, Aluminum alloy window etc
|
|
Canopy
|
Color corrugated steel sheet, Sandwich panel
|
|
Skylight
|
Polycarbonate sheet 0.8/1.2mm
|
|
Roof ventilation
|
Monitor or natural ventilator
|
|
Bolt
|
Foundation anchor bolt 10.9S 8.8S, Commercial bolt 4.8S, Expansion bolt.
|
|
Accessories
|
Screw, Rivet, Foam closures, Sealant, Ventilator, etc
|
Steel warehouse construction has become a popular choice for large warehouse needs. Steel-framed warehouses are known for their vast and spacious interiors. Building a steel warehouse can reduce construction costs, making it more profitable for factories and large warehouses compared to traditional construction methods.
This prefabricated steel warehouse structure is unique because it can be built quickly and easily.
Steel warehouse construction using steel offers many advantages, making it a popular choice for various industries. Here are some of the benefits:
1. High Strength and Durability
Steel construction provides excellent strength to withstand heavy loads, extreme weather conditions, and daily warehouse operations. The durable steel is also highly resistant to corrosion and fire, providing additional protection for the goods stored inside the warehouse.
2. Fast Construction Process
The construction process using steel is relatively quick because steel components can be cut, shaped, and assembled off-site. This reduces on-site construction time and allows for faster installation.
3. Design Flexibility
Steel warehouse construction allows for high design flexibility, including wide spans without additional columns. Large storage space requirements can rely on the more flexible steel warehouse construction. The warehouse can be designed to accommodate specific storage needs and equipment like large racks or cranes.
4. Long-Term Use
Steel has a long service life with low maintenance costs. It is also a reusable material once dismantled.
5. Easy Adaptation and Expansion
Steel warehouse construction is easy to modify or expand without the need for extensive construction. This flexibility allows for adaptation to business growth or the addition of new facilities.
6. Earthquake Resistance
Steel frames have the ability to absorb seismic energy, making them a safe choice in earthquake-prone areas. Their structural flexibility allows steel structures to withstand lateral forces that often occur during earthquakes.
7. Good Fire Resistance
Steel construction for buildings is generally fire-resistant, such as the LGS material from Tradecorp, which uses high-quality cold-formed steel that is fire-resistant. This material prevents the spread of fire and ensures the safety of goods and products.
