Fast Installation Earthquake Resistant Energy Efficient Prefabricated Modular Home Steel Structure House

Brand Name : KXD

Model Number : KXD-SSW1059

Certification : ISO, SGS, CE, BV

Place of Origin : Qingdao

MOQ : 200 Square Meters (MOQ)

Price : US$50.00-100.00

Payment Terms : T/T

Supply Ability : 5000ton/Month

Delivery Time : 30days

Packaging Details : pallet

Warranty : 1 Year

Material Grade : Q235(ASTM G30), Q355(ASTM G50)

Door : Roller Shut

Fire Resistance : High

Contact Now

Fast Installation Steel Structure Factory Prefabricated Living Family Integrated Modular Homes House

Basic Information

Model No. KXD-PH15

Wall and Roof Sandwich Panel Thermal Insulated Roof and Wall

Connect Method Welding or Bolt

Size According to The Need of Design

Window Aluminium Alloy

Door Security Door

Delivery Port Qingdao Port

Delivery Time About 35 Days

Steel High Strength Steel

Warranty 10 Year Limited Warranty

Material Steel Structure

Usage Warehouse, Temporary Offices, Workshop

Certification CE, ISO, SGS, BV

Customized Customized

Transport Package Seaworthy Package

Specification SGS ISO

Trademark kxd

Origin Qingdao, China

HS Code 9406900090

Production Capacity 300 Sets/Month

Product Overview

Fast Installation Steel Structure Prefabricated house designed for quick assembly and durable performance.

Company Profile

Fast Installation Earthquake Resistant Energy Efficient Prefabricated Modular Home Steel Structure House

Key Features

Repeatable Disassembling & Thermal Insulation: Highly accurate pre-punched bolt hole placement using latest technology for faster field assembly
Earthquake Resistant: Specifically engineered to resist building damage caused by major earthquakes
Energy Efficient: Sophisticated isolation material using hypo-allergenic polyethylene foam or mineral foam, reflecting 97% of radiant heat
Professional Installation: Installation according to technical specifications established by the destination country
Fast Delivery: First shipment leaves shortly after contract signing and payment execution, loaded in 40 or 20 feet closed dry ocean containers

Customer Factory Visits

Technical Specifications

No.	Sort	Members	Descriptions
1	Measurement	length Roof Single Span Wall Single Span Clear height Roof pitch	customized customized customized KXD can do 3 stories buildings with light gauge framing system slope is 1:20(1.15°)~1:50(2.8°)
2	Specification	Roof	5:12 Roof slope; Roof truss at 24" (609 mm) O.C. connected to wall tracks R30 Fiberglass insulation in the roof truss cavity 1/2"(12mm) OSB board on top of the truss chord Waterproof attached to OSB board Mason tile, corrugated metal tile, asphalt tile or terracotta tile shingle roofing (Standard) 1/2"(12mm) Gypsum board for inside ceiling
		Exterior wall	3.5" (89 mm) Wall studs spaced at 16" (406 mm) or 24" (609 mm) O.C. anchored to the foundation R13 Fiberglass Insulation in the wall stud cavity 1/2" (12 mm) OSB Board Covered On the Outside of the Stud Flange Breathing paper 5/16" (8mm) cement Siding on the Outside surface of the Exterior Wall Paint on the siding 1/2" (12mm) Gypsum Board on the Inside Surface
		Interior Wall	3.5" (89 mm) Wall studs spaced at 16" (406 mm) or 24" (609 mm) O.C. anchored to the foundation 5.5" (140 mm) Wall studs spaced at 16" (406 mm) or 24" (609 mm) O.C. in bathrooms for plumbing system 1/2" (12mm) Gypsum board or waterproof Gypsum board on both Sides of the wall frames Normal interior door, c/w frame and casing Wall tiles in part of Bathroom and Kitchen
		Floor	10" (250 mm) or 12"(300mm) Floor Joists spaced at 16" (406 mm) or 24" (609 mm) O.C 3/4" (18mm) OSB Board on floor joists 1/2" (12mm) Gypsum board for the ceiling Tiles in Bedrooms & living room Tile flooring in Bathrooms and Kitchen MDF Baseboard
		Kitchen	Laminate Panel Cabinets c/w hinges & laminated panel doors (Standard) Brushed nickel handles & knobs on doors & drawers Granite countertops c/w backsplash Stainless sink c/w chromed goose neck faucet with sprayer
		Bathroom	60" (1524 mm) Bath tub c/w chromed shower faucets Toilet 1.6 Gal. per flush Granite countertop vanity Lavatories c/w chromed faucets Laminate Panel Cabinets c/w hinges & laminated panel doors (Standard)
		Others	Steel stairs included Plumbing and Electrical pipes (wires) systems excluded
		Channel	Galvanized Steel Plain Sheet press molding Material: Q235. Painted

Frequently Asked Questions

What kind of company are you?

We are a steel structure building manufacturer located in Qingdao, China, known for professional, warm and thoughtful service. Our long-term business relationships are built on quality control, competitive pricing, proper packaging, and reliable delivery times.

Is your company a factory or trading company?

We are a factory, which allows us to offer the best competitive prices. Our manufacturing facility covers an area of 150,000 square meters.

What quality assurance do you provide and how do you control quality?

We have established comprehensive procedures to check products at all stages of the manufacturing process - from raw materials and in-process materials to validated/tested materials and finished goods.

Can you offer designing service?

Yes, we have over 100 design engineers who can create full solution drawings according to your requirements. They utilize professional software including Auto CAD, PKPM, MTS, 3D3S, Tarch, and Tekla Structures.

Do you offer guiding installation on site overseas?

Yes, we can provide installation supervision and training services. We can send professional technical engineers to supervise installation on overseas sites. We also maintain our own abroad installation guidance team consisting of more than 30 experienced professionals.
